Ch. 13. Cell Body and Sample Stage Guide Sec. 13.1. Cell Body Guide
Part # Holder Description Front Photo Back Photo
901.760
Fluid
This cell is the same
ast the Gas cell, but
it does not have
electrical
feedthroughs.
13.1.2. Gas Cell
The Gas cell has three magnetic contacts which can be used to route electrical signals to the sample.
(a) Electrical Connector (b) Magnetic Contacts
Figure 13.2.: Gas Cell Body
13.1.2.1. Parts list
Itm Part # Item Description Qty Picture
1 Gas Cell Body. 1
The scale in the photos is in cm and mm.
