Ch. 13. Cell Body and Sample Stage GuideSec. 13.3. Sample Stage / Cell Body Disassembly
5.
Tighten the screws:
• Using a 1.7mm flat tipped screwdriver, tighten all the screws.
• First tighten them in the pattern shown for the first four. When all 8 screws are snug,
go around once more and tighten firmly while holding the tool only with fingertips to
prevent over-tightening.
NOTE: Be careful not to slip and possibly puncture the membrane with the screwdriver.
6.
Finished:
• Your parts should now be as shown to
the right.
7.
Preforming the diaphragm:
• Gently press the sample stage as shown
so the diaphragm pops through to the
other side.
DRAFT
Page 163
