Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
c)
Once the scanner cable is released, slide
the scanner all the way out. Anticipate the
significant weight of the scanner as you
slide it off the rails.- HANDLE
CAREFULLY. Set the scanner aside. It has
rubber feet and can be set on any level
surface.
2. Remove any cantilever holders from scanner stage and set them aside.
a)
Use the .050 WIHA Allen Wrench to
unscrew the screw on the silver
plate-ONLY ¼ turn!!!
b) Once unscrewed a ¼ turn - gently pull the cantilever holder out and set it aside (The can-
tilever holders ship in the accessory Kit Box along with their accessories (See on page 260).
Only the scanner goes in the scanner box.)
3. If customer shipment – Clean scanner for fingerprints – careful on top!
4.
Place the scanner in an anti-static bag.
BETA
Page 240
