Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
1.
Loosen the 2 side screws (only loosen from
Enclosure – do not remove completely) using
the 3/32 Hex Driver.
2.
Remove the piece of foam from inside the
chassis nearest the backpack screws you just
loosened.
3.
Disconnect the ground cable (yellow & green
cable) by pulling apart the pink connectors.
4.
Next, put your hand inside the chassis and
release the pass through the board from the
chassis by popping it out away from the
chassis.
