Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
g)
Unscrew the left door top inside screws
and set them aside (note: There may only
be 1 screw on each side). (SCREW INFO:
8-32 x ½ BHCS SS.
h) Open the door on the right all the way.
i)
Remove the top enclosure cover by
wiggling it – BE CAREFUL: SIDES ARE
SHARP! – then set it aside.
4. Leave the enclosure as it is; we will return to it later in Section 21.4.5 on page 248.
21.4.3. Backpack: Removal and Packaging
STOP!! Call or otherwise contact Asylum Research and talk to us before moving anything. Chances
are that with a few phone calls and the help of this chapter you can do the job yourself. Not calling us
will likely result in instrument damage, costly repairs and downtime, and the voiding of your warranty.
Materials
991.018: Cardboard Carton 18”x18”x6” –
990.038: Foam (Backpack)
Tools 290.134: 3/32” Hex Driver
Final Wt 15 lbs / 7 kg
Minimum Preparation System Shut Down: (
Section 21.3 on page 238)
Enclosure Top Removal: (Section 21.4.2 on page 242)
