Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
d)
Remove all 4 screws from back edge of the
enclosure top plate. They are visible above
the backpack. (SCREW INFO: 8-32 x ¼
BHCS SS)
e)
Unscrew 2 screws in the right door on the
bottom and set aside (note: there may only
be 1 screw) - (SCREW INFO: 8-32 x ½
BHCS SS).
f)
Unscrew the right door top inside screws
and set them aside (note: There may only
be 1 screw on each side). (SCREW INFO:
8-32 x ½ BHCS SS.)
BETA
Page 243
