Ch. 21. Shipping or Moving Sec. 21.4. Shipping a Complete Cypher AFM System
8.
Replace the bridge in the front top of the
enclosure. Slide it in so the screw holes and
foam line up.
9. Screw in 2 screws to secure the bridge.
10. Close the enclosure door and latch the side lock.
11. If customer system – clean all Glass and fingerprints off
12.
Tape the side lock down with Kapton tape.
13.
Prepare the box and foam. Note the cutout in
the foam which aligns with the rear of the
enclosure.
14.
Carefully –with 2 people – lift the enclosure
and place in the bottom of the box, but on top
of the foam. CAUTION: VERY HEAVY –
ABOUT 90 LBS!
BETA
Page 250
