Ch. 6. Fluid Imaging in a Droplet Sec. 6.6. Cleaning and Repair
2.
Loosen the piezo preload screw
Tools 0.028” hex driver or Allen wrench
• Loosen the piezo preload setscrew ¼
turn.
3.
Remove the spring clip
Tools T5 x 40 Torx driver
• Remove the screw securing the spring
clip to the droplet holder body.
• Remove the clip from the droplet holder
body.
• Set the parts aside for cleaning.
BETA
Page 71
