2.6.2. Installation
2.6.2. 1) Connect to the measurement instrument
a) J5 RS485 connector (remote control)
2
1
4
3
Allows the connection of an intelligent remote control.
(Female Lumberg type connector). Optional.
PIN 1 Network
PIN 2 Power supply + 24V
PIN 3 Network
PIN 4 Ground 0V
2.6.2. 2) Connector on the RC5
a) RS485 connector (Input)
2 1
4
3
Allows the connection of the option to the remote control
input of the ATEQ instruments. (Male Lumberg type
connector).
PIN 1 Network
PIN 2 Power supply + 24 V
PIN 3 Network
PIN 4 Ground 0V
2.6.3. Start-up
Before connecting the instruments, turn them off, when the network is installed it
automatically detects the presence of the RC5 remote front panel when the instrument
is switched on.
If the remote front panel is equipped with a multifunction intelligent remote control (8
keys) refer to the paragraph concerning this accessory.
