2.14. BAR CODE OPTION
2.14.1. Definition
The “Bar code” option enables to install a bar code reader on a second specific RS232
connector of the 5th series ATEQ instruments.
It enables on reading of the code to select a test program and eventually to launch the
test of control (if the option is validated).
The quantity of characters read by the reader should not exceed 22. Beyond the unit will
not take into account the character string (bar code string).
This option is valid for the units starting from the last version ATEQ devices.
2.14.2. Communication parameters configuration
The Bar Code reader must be set with the following communication parameters:
¾ 9600 bauds,
¾ 7 bits,
¾ 1 stop,
¾ Parity even.
The communication parameters of the ATEQ devices are the same by default and fixed,
it's not provide to change it.
2.14.3. Function activation
Warning: each change of parameters or configuration will reset all the learning. It will
be necessary to learning again all the bar codes for each programs.
From the main menu, put the
cursor in front of
CONFIGURATION.
MAIN MENU
SPE CYCLE : Disable
CONFIGURATION
RESULTS
Select the BAR CODE
function and validate by YES.
CONFIGURATION
BARCODE : Yes
SECURITY : No
LIGHT
Then appears the parameters
of reading of the bars codes,
which it is advisable to inform.
CONFI/BARCODE
Pr. Select : No
Reset EOC : No
The "Select Pr." parameter enables to select the paired program to the bar code
number. When the bar code is learned, when flashed, the corresponding program will
be selected as the active program.
