ATEQ D520 - Cycle Keys; Key Lock

Chapter 2 – User interfaces
UM-22100H-U User manual ATEQ D520 Page 29/122
2.2. CYCLE KEYS
KEY FUNCTION
START key
Launching a measurement cycle
Reset key (Reset to 0)
Stopping of the measurement cycle in
progress
3. KEY LOCK
POSITION FUNCTION
LOCK position.
The access to the adjustable parameters is
not possible.
ACCESS position.
Access to the adjustable parameters.
Note: whatever the position of the key-lock is (LOCKED or ACCESS), it is possible to
start and stop test cycles.
