Chapter 1 – Installation of the instrument
UM-22100H-U User manual ATEQ D520 Page 15/122
Chapter 1
INSTALLATION OF THE INSTRUMENT
1. PRESENTATION OF THE ATEQ D520
C
<>
www.ateq.com
D520
N
.
The ATEQ D520 is presented in a painted and formed metal case which rests on four
rubber feet. The upper cover is linked to the structure with 2 screws.
The format of the case has been reduced to allow easy insertion of the instrument.
The instrument is delivered with an external 24 V DC power supply.
