Chapter 4 – Functions of the instrument
UM-22100H-U User manual ATEQ D520 Page 78/122
2.9. RS232
2.9.1. C540/580
This function enables the configuration of the instrument so that it may be supervised by
an ATEQ central module.
) Select the option and enter settings if necessary.
2.9.2. Printer
This function is used to configure the instrument so that the data relating to the
programs (parameters) and the test results can be printed. When the option is activated
(YES), the test results are automatically printed each time a cycle is started.
) Select the option and enter settings if necessary.
2.9.2. 1) RS parameters
These parameters are used to configure the instrument for dialogue with the printer.
Associated parameters to be set: Speed (bit rate transmission), stop bit, data bit
number, parity.
) Select the option and enter settings if necessary.
2.9.2. 2) Frame
This function allows the configuration of the results frame.
Associated parameters to be adjusted: PRESSURE (Display of the test pressure or
not), Personalization (Display of the program name when there is one), Timekeeper
(printing of the date and the time), Before result (number of lines before the result),
After result (number of lines after the result), Inter Line (space between each line).
