ATEQ D520 User Manual

Chapter 4 – Functions of the instrument
UM-22100H-U User manual ATEQ D520 Page 47/122
Chapter 4
FUNCTIONS OF THE INSTRUMENT
1. MENU STRUCTURE
1.1. MAIN MENU
MAIN MENU Sub menu 1 Sub menu 2 Sub menu 3 Sub menu 4
RUN PROGRAM
> 1 to 64
RUN SEQUENCE
> SQ01 to SQ32
v
SEQUENCE
> SEQ. UTILITY > Copy
v
v Paste
v
v Delete Name
v
v Delete Sequence
v
v
v
SQ01 to SQ32 > Name
v
Steps
<01> to <16>
These functions
appears only if the
sequence mode
(SEQUENCE) is
validated (Yes) in
the
CONFIGURATION
menu
v
PARAMETERS
> Copy Paste > Copy
v
v Paste
v
v
v
Programs
01 to 64
>
DIRECT FLOW
(or INDIRECT)
>
Type: direct flow
(or indirect)
> Delete name
v
v
Range (2
nd
capillary option)
Delete program
v
v Coupling A Delete name CAL
v
v Fill
v
v Stabilization
Test
v
v Dump
v
v Pressure unit >
Bar > Mpa > kPa
> Pa > PSI >
mbar
v
v Maximum fill
v
v Minimum fill
v
v Fill instruction
v
v Reject unit >
SI : ml/h > l/s >
ml/s > ml/mn >
ml/h
USA : in
3
/h > ft
3
/h
> in
3
/mn > in
3
/h >
ft
3
/h > in
3
/mn
v
v Maximum reject
v
v Minimum reject
v
v Functions > Refer to note
