ATEQ D520 User Manual

Chapter 3 – Start-up and adjustments
UM-22100H-U User manual ATEQ D520 Page 36/122
2.3. ADJUSTMENT OF THE PARAMETERS
Once the test type is chosen, the cycle parameters must be adjusted.
The procedure to follow to adjust all the test parameters is identical. Example with the
Coupling time A.
First, place the cursor in front
of the chosen parameter with
the navigation keys
(here, wait time A).
PARAM/
P
r001
TYPE : DIRECT FLOW
COUPL. A : 00.00 s
FILL : 00.00 s
Next, confirm with the ENTER
key. The cursor moves to the
right hand side of the screen.
PARAM/
P
r001
TYPE : DIRECT FLOW
COUPL. A : 00.00 s
FILL : 00.00 s
Modify the value with the
navigation keys.
PARAM/P
r001
TYPE : DIRECT FLOW
COUPL. A : 00.03 s
FILL : 00.00 s
Once the value is modified,
confirm with the ENTER key.
PARAM/P
r001
TYPE : DIRECT FLOW
COUPL. A : 03.00 s
FILL : 00.00 s
To move to the next
parameter, use the navigation
keys.
PARAM/P
r001
TYPE : DIRECT FLOW
COUPL. A : 03.00 s
FILL : 00.00 s
To exit the menu, use the
CANCEL key.
C
PARAMET
E
R
S
Copy-Paste
Pr:001 FLOW
Pr:002 FLOW
