ATEQ D520 User Manual

Chapter 4 – Functions of the instrument
UM-22100H-U User manual ATEQ D520 Page 79/122
2.9.2. 3) Format of the frame
The results frame fits on 40 columns.
a) Example for a good test result
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
< 0 1 > : ( P B ) : 1 0 7 . 6 m l / s
Details of the frame:
Columns Characters
1 <
2-3 Number indicating the program number
4 >
5 :
6 (
7 – 8 2 letter indicating OK for a good part,
F+ for a bad part with a high flow,
F- for a bad part with a low flow.
9 )
10 :
11 SPACE
12 – 16 5 numbers indicating the value of the leak
17 SPACE
18 > XX 3 to 6 letters indicating the unit
b) Example for a test result with pressure
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
< 0 1 > : 1 8 . 8 m b a r : ( O K ) : 1 0 2 . 1 m l / s
c) Example for a test result with timekeeping
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
< 0 1 > : 1 0 / 0 4 / 2 0 0 3 1 6 : 0 2 : 4 0
< 0 1 > : 1 8 . 5 m b a r : ( O K ) : 1 0 1 . 8 m l / s
d) Example for a test with an error
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
< 0 1 > : ( A L ) : F . S S c . p i e z o
< 0 1 > : ( A L ) : P R E S S U R E L O W
< 0 1 > : ( A L ) : P R E S S U R E H I G H
