Chapter 4 – Functions of the instrument
UM-22100H-U User manual ATEQ D520 Page 80/122
Details of the frame:
Columns Characters
1 <
2-3 Number indicating the program number
4 >
5 :
6 (
7 – 8 2 letters AL for ALARM
9 )
10 :
11 > XX Error text corresponding to the error
2.9.3. Send conditions
With this function you can choose which data is to be printed on the results sheet.
Associated parameters to be set: ALL (all test results), OK (number of good parts),
MAX (high flow parts), MIN (low flow parts), WARN. (number of times the alarm has
been triggered), PRESS DEF. (number of times pressure was incorrect),
RECUPERABLE (number of recoverable parts).
) Select the option and enter settings if necessary.
2.9.4. Exportation
This function can be used to create and send a special results frame which can be
processed by a PC using Microsoft Excel.
This frame is of the same type as the print parameters frame except that the different
character strings follow each other and are separated by a punctuation mark which
enables the various boxes to be entered automatically in Microsoft Excel.
This frame is operated by connecting a computer to the instrument's RS232 link.
) Select the option and enter settings if necessary.
2.9.5. Print the parameters
By validating this function, the test parameters of the programs activated on the
instrument are instantly printed.
