Chapter 4 – Functions of the instrument
UM-22100H-U User manual ATEQ D520 Page 84/122
2.14.4. Program selection function not validated
If the "Select Pr." Function is not validated (No) the function "Reset EOC" is displayed.
Validate the "Reset EOC".
Function (Yes).
Pr. Select : No
Reset EOC : Yes
1. "Reset EOC" Function not validated (No): the flashed bar code is recorded in the
device memory, and is used for the all serial product until a new number is flashed.
This number will be sent on the device output frame or on the print output.
2. "Reset EOC" Function validated (Yes): the flashed bar code is recorded in the device
memory; it will be used only for the next test cycle and will be deleted at the end of cycle.
This number will be sent on the output frame or on the print output for the current cycle.
If no number is flashed for the next cycle, no number will appears or printed (blank).
2.14.5. Program selection function validated
Validate the "Select Pr."
function (Yes).
Pr. Select : Yes
First char : 05
Char Number : 10
The reading parameters for
the bar code are displayed,
that should be informed.
CONFIG/BAR CODE
Select Pr. : Yes
First char : 05
Char Number : 10
The parameter “First character” corresponds to the position of first character to take in
account in the total string of characters.
The parameter “Char number” corresponds to the quantity of characters (or the length
of the chain) to take in account.
The sum of the two captured parameters must be lower or equal to the total quantity of
characters contained in the chain plus 1.
Σ Parameters ≤ Total quantity of characters + 1 ≤ 22
Adjust the values of the
parameters using the keys high
and low, then validate with the
ENTER key.
CONFIG/BAR CODE
Select Pr. : Yes
First char : 05
Char Number : 10
Example: the program will be
selected if the unit reads the
character chain:
E F G H I J K L M N.
A B C D E F G H I J K L M N O P Q R S T U V
5
10 characters
Number total of characters = 22
If a same characters string is on several programs, the program with the smallest
number will be selected the others will be ignored.
