Atlas Copco FlexiROC T30 R User Manual

FlexiROC T30 R 5 Transport
101 No: 2969809547.1.2969824267 en-US
5.4 Before Transporting Loaded Drill Rig
WARNING
Tipping Risk
The tipping over of a machine can cause serious injury or death.
u Lock the track oscillation before hoisting the machine.
u Adapt transportation equipment to the dimensions and weight of the machine.
u Check that all hatches are properly locked.
Tramming position Alternative 1
Tramming position Alternative 2
Precondition
p
Straps or chains are attached to the lifting eyes on the machine and transport vehicle.
1.
Extract the hydraulic jack.
2.
Track oscillation cylinders to locked position.
3.
Support the feed beam against the vehicle to prevent overloading.
4.
Switch off the diesel engine.
5.
Strap the drill rig securely to the vehicle.
