FlexiROC T30 R 4 Operation
73 No: 2969809547.1.2969824267 en-US
5.
Reduce the winch cable pressure gradually until the drill rig can be driven smoothly
down the incline with a suitable counterbalance from the winch. Make sure that the
cable remains taut constantly.
!
NOTE: The winch wire is always retracted on activation or tram-
ming. On tramming forward, the inward motor extends the wire from
the hydraulic system. R106 determines the force that is necessary
for the winch to be retracted.
Header 1
Diesel engine, Caterpillar Power output at 1900 rpm 242 kW
Temperature range in operation -25° to +50°C
Tramming speed, maximum 3.4 km/h
Tractive force 112 kN
Ground pressure, average 125 kPa
Ground clearance 405 mm
Maximum hydraulic pressure 280 bar
Track oscillation ±10 °
Track oscillation ±10 °
4.2.14 Checking after Tramming
All emergency stops must be checked for proper function after tramming.
