FlexiROC T30 R 4 Operation
76 No: 2969809547.1.2969824267 en-US
2.
Hold the hole depth reset button
for five seconds.
è
The blasting direction is now locked and the angles in the display are locked
even though the aiming device is moved.
!
NOTE: If the angles change when turning the aiming device,
the GPS compass does not work.
4.4 Drilling
4.4.1 Safety Precautions Before Drilling
WARNING
Moving Parts
Moving parts can cause serious injury.
u Ensure that unauthorized personnel are not within the working area.
u Do not approach the area surrounding rod or pipe gripper or carousel.
u Always use lifting assistance when loading and unloading the carousel.
u Do not approach the area surrounding rod or pipe when the drill rod support is closed
during loading.
u Only load or unload the carousel when two persons are available.
u Follow the instructions carefully.
WARNING
Accidental Operation
Accidental operation can cause serious injury or damage property.
u The operator must have a clear line of sight when working with a remotely operated
machine.
u Before operating the machine, always check that the controls are correctly adjusted.
u Always deactivate the remote control when not in use.
u Never stand on the machine during operation.
4.4.2 Loading Drill Rod with RAS
1.
Check that the mode switch (B) is in drilling position
(2).
