FlexiROC T30 R 2 Product Description
11 No: 2969809547.1.2969824267 en-US
K Dust collector
L Boom head
M Drill rod support
N Track frame
P Control panel
Q Power Pack
R Platform
S Diesel engine
T Winch
U Compressor
V Electric cabinet with radio unit
X Pressure gauge panel and operator panel
Y Radiator
2.4 Wagon Frame with Track Frames
The wagon frame contains of:
n Diesel engine
n Chassis
n Dust collector
n Hydraulic system
n Air system
n Boom system
The track frames are carried on journals in the chassis frame. Two track oscillation cylin-
ders balance the drill rig when tramming on uneven ground. Each track frame has its own
service brake. Two separate control systems operate the service brakes. The dust collector
is installed at the back of the rig on the right-hand side.
2.5 Power Pack
The turbocharged, water-cooled diesel engine powers the hydraulic drill rig.
The turbocharged, water-cooled diesel engine with an afterburner chamber to reduce emis-
sions, powers the hydraulic drill rig.
The diesel engine is equipped with a monitoring system that includes automatic shutdown
functions.
Two tramming motors with gears drives the drill rig. The tramming motors with gears are
installed in the track frames.
Two traction motors with gears powers the drill rig. The traction motors with gears are at-
tached to the track frames.
The diesel engine drives the hydraulic pumps and the compressor.
