FlexiROC T30 R 7 Technical Data
128 No: 2969809547.1.2969824267 en-US
FlexiROC T30 R -03 Data
Inclination angles - tramming Downward or upward, maximum
without winch
20º/19º
Downward or upward, maximum
with winch
30º/30º
Laterally, maximum 20º/20º
Inclination angles for drill rig
when drilling:
Longitudinally, maximum (up-
ward or downward)
20º/20º
Lateral (left or right) 12º/12º
Extreme sideways positions (left
or right)
5º/7º
7.9 Capacities
Description Data
Hydraulic oil tank 200 l (58 gal)
Hydraulic system, total 250 l (66 gal)
Fuel tank 270 l (71.3 gal)
DEF-tank 14,6 l (3.9 gal)
Traction gear 3 l (0.79 gal
Compressor oil 20 l (5.3 gal)
Lubrication tank ECL 10 l (2.6 gal)
Diesel engine oil 11 l (2.9 gal)
Engine cooling system 31 l (8.2 gal)
7.10 Miscellaneous
Description Data
Fire extinguisher A-B-C powder 1 x 6 kg
