FlexiROC T30 R 8 Options
132 No: 2969809547.1.2969824267 en-US
Description Data
Power Supply 12–28 V DC
Current usage 0.04 A
Operating temperature -20°C - +50°C
Enclosing IP65
Angle measurement Measurement range 2 * 20º
Measurement accuracy 0.5º
8.4 ROC-ANGIE
!
NOTE: It is important to aim ROC-ANGIE in the blasting direction or parallel with the
direction of the drill hole.
ROC-ANGIE measures forward and rearward angles and right and left angles from the ver-
tical position of the feeder. If straight vertical holes are drilled, it is unnecessary to aim
ROC-ANGIE. The machine can stand in any direction at all relative to the bench if ROC-
ANGIE is correctly aimed.
ROC-ANGIE can be turned round a vertical axis and aligned in the desired direction in-
stead of aiming the machine in a special direction at each hole. Use a compass or make an
own aiming point if there is not an aiming point (for example, tree, telegraph). The steel in
the machine can affect the compass needle If using a compass. The angles that are shown
in the receiver are always relative to the aiming point, not to the machine, If ROC-ANGIE is
aimed.
