FlexiROC T30 R 5 Transport
99 No: 2969809547.1.2969824267 en-US
5 Transport
5.1 Preparations Before Hoisting
WARNING
Risk of Crushing
Crushing can cause serious personal injury or death.
u Use extreme caution when slinging and hoisting heavy objects.
u Hoisting must take place at the center of gravity.
u Only use slings that are intact and designed for the load they will carry.
u Fasten the straps to lifting eyes, if available.
u Do not approach a suspended load..
Before transporting in shafts or similar, it may be necessary to fully or partially dismantle
the machine. Observe the following when dismantling, hoisting and assembling:
n Clean the entire machine with water and/or detergent containing a grease solvent be-
fore dismantling.
n Mark hoses, pipes and other connections to make reassembly easier and prevent mix-
ups.
n Make sure that everything is clean when dismantling hydraulic, compressed air and
water flushing hoses. Immediately plug all hoses, nipples and hydraulic oil pipes, or
seal.
n Use properly secured lifting device of generous dimension.
5.2 Before Loading the Machine onto the Transport
Vehicle
WARNING
Tipping Risk
The tipping over of a machine can cause serious injury or death.
u Lock the articulation lock before hoisting the machine.
u Adapt transportation equipment to the dimensions and weight of the machine.
u Check that all hatches are properly locked.
n Position feeders and booms as low as possible.
n Position feeders horizontally.
n To tram onto transport vehicle: Follow separate driving instruction sheet.
n To lift the machine onto transport vehicle: Use adequate lifting device and attach only
to marked lifting points.
