FlexiROC T30 R 3 Controls and Instrument
37 No: 2969809547.1.2969824267 en-US
Symbol Function Description
Water mist, On or Off
Track oscillation lock, On or Off
Flushing air, On or Off
Disengaging the damper pres-
sure
Active when the button is
pressed and held. Applies to the
COP 3060.
Remote control On or Off The button is pushed until the
display is switched on. The
levers must be in start position
when the remote control is
started.
Automatic break loose On or Off Press button for 1 second to ac-
tivate.
Switch, Remote Control or Rig The indicator lamp (2) comes on
when the remote control has
control.
Locking the adapter Applies for drilling with Cop Rod
Start or stop button for the diesel
engine
Speed control
Reset button for protection of
moving parts
N/A
Tramming Low Speed
