The APIB PCMCIA card and cable
Con nect the small con nec tor on the PCMCIA APIB ca ble to the match -
ing con nec tor on the PCMCIA card. Turn off your lap top and slide the
card into an open PC card slot. Con nect the other end of the APIB ca ble
to the in stru ment. Turn on you lap top and launch ATS.
Note: if your PC is fitted with more than one APIB interface
adapter,when ATS is launched Microsoft Windows will select
one to communicate with the software. An installed
USB-APIB adapter will have priority.
Connecting ATS-2 to Your PC Chapter 2: Installation and Setup for APIB
Getting Started with ATS-2 15
INSERT HERE
PCM-WINPCM-WIN
PCMCIA to
Audio Precision
Interface Bus
APIB
For use with S1.EXE, LIB-C or APWIN
Figure 10. USB-APIB adapter and cables.
