Audio Precision ATS-2 User Manual

Chapter 3
Hardware Overview
The ATS-2 hard ware in cludes in put and out put con nec tors, rang ing and
sig nal con di tion ing mod ules, dig i tal sig nal pro ces sors, mem ory, and other
cir cuitry needed to per form au dio mea sure ments. It is con nected to the
con trol ler PC by the Au dio Pre ci sion In ter face Bus (APIB). In this chap ter,
the fea tures of the hard ware are de scribed. For a full list of hard ware spec i -
fi ca tions, see Chap ter .
When or dered in the op tional GPIB con fig u ra tion (ATS2G), ATS-2 can
also be con trolled by the in dus try-stan dard IEEE 488.2 Gen eral Pur pose
In ter face Bus (GPIB). GPIB op er a tion is not cov ered in this chap ter. See
Chap ter 7 for more in for ma tion about the ATS-2 GPIB configuration.
All sig nal gen er a tion and anal y sis is per formed in the ATS-2 hard ware,
in clud ing stor age of sig nals ac quired for DSP wave form dis play or FFT
analysis.
ATS-2 Front Panel
The ATS-2 front panel, shown in Fig ure 11, in cludes the dig i tal and an -
a log in puts and out puts and a power in di ca tor.
Getting Started with ATS-2 17
Digital Output
Digital Input Analog Inputs Power Indicator
Analog Outputs
Figure 11. ATS-2 front panel.
