Chapter 7
GPIB Configuration
Introduction
As an op tion, ATS-2 can be or dered in its GPIB con fig u ra tion, model
ATS2G. GPIB ca pa bil i ties can also be added to ATS-2 af ter pur chase with
the in stal la tion of a GPIB up grade at the Au dio Pre ci sion fac tory or at a
fac tory-au tho rized representative.
The GPIB con fig u ra tion brings the IEEE-488.2 in ter face stan dard, also
known as the Gen eral Pur pose In ter face Bus or GPIB, to ATS-2. Hard ware
for GPIB con sists of a cir cuit board mounted on a con nec tor panel as sem -
bly that is fit ted in the re served space on the ATS-2 rear panel, as shown
below.
APIB or GPIB?
ATS-2 is nor mally con trolled by Au dio Pre ci sion’s ATS mea sure ment
soft ware us ing the APIB in ter face bus. In the GPIB con fig u ra tion, ATS-2
Getting Started with ATS-2 59
ERR
MAV
LA
TA
SRQ
GPIB
GPIB
IEEE-488.2 (GPIB)
4
0
1
2 18 16
APIB
ADDRESS
RL1, PP0, DC1, DT1, C0, E2
SH1, AH1, T6, TE0, L4, LE0, SR1,
Headphone
Jack
APIB
Auxiliary
Control Out
Auxiliary
Control In
Ground
Connector
S/N, Option
Label
Fuse
Replacement
Information
Power
Cord
Connector
Power
Entry
Module
Power
Switch
Mains Voltage
Indicator
GPIB Panel
Fuse Holder /
Mains Supply
Voltage Jumper
Sync / Ref In
Monitor
Outputs
Trig In Trig Out
Figure 22. Rear panel, ATS-2 with GPIB Option.
