Flatness
4
±1 dB, 100 Hz to 20 kHz
Residual Jitter
5
£2 ns [0.012 UI at 48 kS/s, 0.024 UI at 96 kS/s]
Spurious Jitter Products typically <0.003 UI [–50 dBUI] or 30 dB below
jitter signal, whichever is larger
Audio Analyzer
Level and Amplitude Measurement
(Independent level and amplitude meters per channel)
Measurement Range
Analog <1 µV rms to 140 V rms [–118 dBu to +45.1 dBu]
Digital –120 dBFS to 0 dBFS (usable to –140 dBFS)
Accuracy (1 kHz)
Analog ±0.09 dB [±1.0%]
Digital ±0.002 dB [±0.023%]
Flatness
6
Analog ±0.01 dB, 20 Hz to 20 kHz (0.45´SR if less);
±0.10 dB, 10 Hz to 120 kHz (with performance
option)
Digital ±0.002 dB, 10 Hz to 0.45´SR
Detection RMS, FAST RMS, or QPK per IEC 468 (CCIR)
Frequency Measurement
(Two independent meters, one per channel)
Range
Analog <10 Hz to 30 kHz (SR = 65.536 kS/s),
<10 Hz to 120 kHz (with performance option)
Digital <10 Hz to 0.47´SR
Accuracy ±0.0003% [3 PPM]
Resolution 0.00001% of SR [0.007 Hz at 65.536 kS/s]
Minimum Input
Analog 1 mV (S/N >40 dB)
Digital –100 dBFS (S/N >40 dB)
Phase Measurement
Measurement Ranges
±180, –90 to +270, or 0 to +360 deg
Chapter 6: Specifications
50 Getting Started with ATS-2
4
System specification including contributions from both analyzer and generator. Valid at
32.0, 44.1, 48.0, 65.536, 88.2, and 96.0 kS/s only. Flatness may degrade at other
sample rates.
5
System specification valid only if (1) the jitter generator amplitude is turned off; (2) the
digital input is ³ 1.0 Vpp (XLR) or ³ 250 mVpp (BNC); and (3) the analyzer is set for
700 Hz–100 kHz bandwidth.
6
1 kHz ref. Flatness derates above 5 kHz by an additional ±0.02 dB in the 22.4 V, 45 V,
90 V, and 200 V input ranges.
