Version 5.2 151 September 2007
SIP User's Manual 5. Web-based Management
Table 5-26: Voice Mail Parameters
Parameter Description
Forward on No Answer
Digit Pattern (Internal)
[DigitPatternForwardOnN
oAnswer]
Determines the digit pattern used by the PBX to indicate 'call forward on
no answer' when the original call is received from an internal extension.
The valid range is a 120-character string.
Forward on Do Not Disturb
Digit Pattern (Internal)
[DigitPatternForwardOnD
ND]
Determines the digit pattern used by the PBX to indicate 'call forward on
do not disturb' when the original call is received from an internal
extension.
The valid range is a 120-character string.
Forward on No Reason
Digit Pattern (Internal)
[DigitPatternForwardNoR
eason]
Determines the digit pattern used by the PBX to indicate 'call forward
with no reason' when the original call is received from an internal
extension.
The valid range is a 120-character string.
Forward on Busy Digit
Pattern (External)
[DigitPatternForwardOnB
usyExt]
Determines the digit pattern used by the PBX to indicate 'call forward on
busy' when the original call is received from an external line and not an
internal extension.
The valid range is a 120-character string.
Forward on No Answer
Digit Pattern (External)
[DigitPatternForwardOnN
oAnswerExt]
Determines the digit pattern used by the PBX to indicate 'call forward on
no answer' when the original call is received from an external line and
not an internal extension.
The valid range is a 120-character string.
Forward on Do Not Disturb
Digit Pattern (External)
[DigitPatternForwardOnD
NDExt]
Determines the digit pattern used by the PBX to indicate 'call forward on
do not disturb' when the original call is received from an external line and
not an internal extension.
The valid range is a 120-character string.
Forward on No Reason
Digit Pattern (External)
[DigitPatternForwardNoR
easonExt]
Determines the digit pattern used by the PBX to indicate 'call forward
with no reason' when the original call is received from an external line
and not an internal extension.
The valid range is a 120-character string.
Internal Call Digit Pattern
[DigitPatternInternalCall]
Determines the digit pattern used by the PBX to indicate an internal call.
The valid range is a 120-character string.
External Call Digit Pattern
[DigitPatternExternalCall]
Determines the digit pattern used by the PBX to indicate an external call.
The valid range is a 120-character string.
Disconnect Call Digit
Pattern
[TelDisconnectCode]
Determines a digit pattern that, when received from the Tel side,
indicates the gateway to disconnect the call.
The valid range is a 25-character string.
MWI
MWI Off Digit Pattern
[MWIOffCode]
Determines a digit code used by the gateway to notify the PBX that there
aren't any messages waiting for a specific extension. This code is added
as prefix to the dialed number.
The valid range is a 25-character string.
MWI On Digit Pattern
[MWIOnCode]
Determines a digit code used by the gateway to notify the PBX of
messages waiting for a specific extension. This code is added as prefix
to the dialed number.
The valid range is a 25-character string.
