Version 5.2 169 September 2007
SIP User's Manual 5. Web-based Management
2. Configure the Fax / Modem / CID Settings according to the table below.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, refer to 'Saving Configuration' on page 256.
Table 5-33: Media Settings -- Fax/Modem/CID Parameters
Parameter Description
Fax Transport Mode
[FaxTransportMode]
Fax Transport Mode that the gateway uses.
 [0] Disable = transparent mode.
 [1] T.38 Relay = (default).
 [2] Bypass.
 [3] Events Only.
Note: If parameter IsFaxUsed = 1, then FaxTransportMode is always
set to 1 (T.38 relay).
Caller ID Transport Type
[CallerIDTransportType]
Defines the Caller ID Transport type.
 [0] Disable = Disable
 [1] Relay = Relay
 [3] Mute = Mute
V.21 Modem Transport Type
[V21ModemTransportType]
V.21 Modem Transport Type that the gateway uses.
 [0] Disable = Disable (Transparent) -- default
 [1] Enable Relay = N/A
 [2] Enable Bypass.
 [3] Events Only = Transparent with Events.
V.22 Modem Transport Type
[V22ModemTransportType]
V.22 Modem Transport Type that the gateway uses.
 [0] Disable = Disable (Transparent)
 [1] Enable Relay = N/A
 [2] Enable Bypass = (default)
 [3] Events Only = Transparent with Events
V.23 Modem Transport Type
[V23ModemTransportType]
V.23 Modem Transport Type that the gateway uses.
 [0] Disable = Disable (Transparent)
 [1] Enable Relay = N/A
 [2] Enable Bypass = (default)
 [3] Events Only = Transparent with Events
V.32 Modem Transport Type
[V32ModemTransportType]
V.32 Modem Transport Type that the gateway uses.
 [0] Disable = Disable (Transparent)
 [1] Enable Relay = N/A
 [2] Enable Bypass = (default)
 [3] Events Only = Transparent with Events
Note: This option applies to V.32 and V.32bis modems.
