SIP User's Manual 222 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-47: SNMP Trap Destinations Table Parameters
Parameter Description
SNMP Manager
[SNMPManagerIsUsed_x]
Up to five parameters, each determines the validity of the parameters
(IP address and port number) of the corresponding SNMP Manager
used to receive SNMP traps.
 [0] (Check box cleared) = Disabled (default)
 [1] (Check box selected) = Enabled
IP Address
[SNMPManagerTableIP_x]
Up to five IP addresses of remote hosts that are used as SNMP
Managers. The device sends SNMP traps to these IP addresses.
Enter the IP address in dotted format notation, for example
108.10.1.255.
Trap Port
[SNMPManagerTrapPort_
x]
Up to five parameters used to define the Port numbers of the remote
SNMP Managers. The device sends SNMP traps to these ports.
Note: The first entry (out of the five) replaces the obsolete parameter
SNMPTrapPort.
The valid SNMP trap port range is 100 to 4000. The default SNMP trap
port is 162.
Trap Enable
[SNMPManagerTrapSendi
ngEnable_x]
Up to five parameters, each determines the activation/deactivation of
sending traps to the corresponding SNMP Manager.
 [0] Disable = Sending is disabled
 [1] Enable = Sending is enabled (default)
5.10.2 Configuring the SNMP Community Strings
The 'SNMP Community String' screen is used to configure up to five read-only and up to
five read / write SNMP community strings, and to configure the community string that is
used for sending traps. For detailed information on SNMP community strings, refer to the
SIP Series Reference Manual.
¾ To configure the SNMP Community Strings, take these 5 steps:
1. Access the 'Management Settings' screen (Advanced Configuration menu >
Management Settings); the 'Management Settings' screen is displayed (refer to
'Configuring the Management Settings' on page 218).
2. Open the 'SNMP Community String' screen by clicking the arrow sign (-->) to the right
of the SNMP Community String label.
