SIP User's Manual 5. Web-based Management
Table 5-30: IP Routing Table Column Description
Column Name
[ini File Parameter Name]
Description
The address of the host / network you want to reach is determined by an AND operation that is
applied on the fields 'Destination IP Address' and 'Destination Mask'.
For example:
To reach the network 10.8.x.x, enter 10.8.0.0 in the field 'Destination IP Address' and 255.255.0.0 in
the field 'Destination Mask'. As a result of the AND operation, the value of the last two octets in the
field 'Destination IP Address' is ignored.
To reach a specific host, enter its IP address in the field 'Destination IP Address' and
255.255.255.255 in the field 'Destination Mask'.
Gateway IP Address
[RoutingTableGatewaysColumn]
Specifies the IP address of the router to which the
packets are sent if their destination matches the rules in
the adjacent columns.
TTL
A read-only field that indicates the time period for which
the specific routing rule is valid. The lifetime of a static
route is infinite.
Hop Count
[RoutingTableHopsCountColumn]
The maximum number of allowed routers between the
gateway and destination.
Network Type
[RoutingTableInterfacesColumn]
Specifies the network type the routing rule is applied to.
 [0] OAM (default).
 [1] Control.
 [2] Media.
For detailed information on the network types, refer to
'Multiple IPs' on page 373.
