Page #190 background image
SIP User's Manual 190 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-37: E1/T1/J1 Configuration Parameters
ini File Field Name
Web Parameter Name
Valid Range and Description
CAS Configuration
CAS Table
[CASTableIndex_x]
Defines CAS protocol for each trunk ID from a list of CAS protocols
defined by the parameter CASFileName_Y.
For example:
CASFileName_0 = 'E_M_WinkTable.dat'
CASFileName_1 = 'E_M_ImmediateTable.dat'
CASTableIndex_0 = 0
CASTableIndex_1 = 0
CASTableIndex_2 = 1
CASTableIndex_3 = 1
Trunks 0 and 1 use the E&M Winkstart CAS protocol, while trunks 2 and
3 use the E&M Immediate Start CAS protocol.
Note: For additional CAS table ini file parameters (CASFileName_0,
CASFileName_1, CASFileName_7, and CASTablesNum), refer to 'E1/T1
Configuration Parameters' on page 307.
Dial Plan
[CasTrunkDialPlanName]
The Dial Plan name that is used on a specific trunk.
The range is up to 11 character strings.
Miscellaneous
PSTN Alert Timeout
[TrunkPSTNAlertTimeout
_ID]
Alert Timeout (ISDN T301 timer) in seconds for outgoing calls to PSTN.
This timer is used between the time that SETUP is sent to the Tel side
(IP-to-Tel call establishment) and CONNECT is received. If ALERT is
received, the timer is restarted.
The ID is the trunk number (0 - 7).
The range is 1 to 600. The default is 180 seconds.
