AudioCodes Mediant 2000 System User Manual

SIP User's Manual 194 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-38: CAS State Machine Parameters
Parameter Description
DTMF Min Detection Time
[CasStateMachineDTMFMin
OnDetectionTime]
Detects digit minimum on time (according to DSP detection
information event) in msec units. The digit time length must be longer
than this value to receive a detection. Any number may be used, but
the value must be less then
CasStateMachineDTMFMaxOnDetectionTime.
The value must be a positive value. The default value is -1.
MAX Incoming Address Digits
[CasStateMachineMaxNumO
fIncomingAddressDigits]
Defines the limitation for the maximum address digits that need to be
collected. After reaching this number of digits, the collection of
address digits is stopped.
The value must be an integer. The default value is -1.
MAX Incoming ANI Digits
[CasStateMachineMaxNumO
fIncomingANIDigits]
Defines the limitation for the maximum ANI digits that need to be
collected. After reaching this number of digits, the collection of ANI
digits is stopped.
The value must be an integer. The default value is -1.
Collet ANI
[CasStateMachineCollectANI
]
In some cases, when the state machine handles the ANI collection
(not related to MFCR2), you can control the state machine to collect
ANI or discard ANI.
 [0] No = Don't collect ANI.
 [1] Yes = Collect ANI.
 [-1] Default = Default value.
Digit Signaling System
[CasStateMachineDigitSignal
ingSystem]
Defines which Signaling System to use in both directions
(detection\generation).
 [0] DTMF = Uses DTMF signaling.
 [1] MF = Uses MF signaling (default).
 [-1] Default = Default value.
