SIP User's Manual 286 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 6-2: System Parameters
ini File Field Name
Web Parameter Name
Valid Range and Description
ExtBootPReqEnable
 [0] = Disable (default).
 [1] = Enable extended information to be sent in BootP request.
If enabled, the device uses the vendor specific information field in the
BootP request to provide device-related initial startup information such
as blade type, current IP address, software version, etc. For a full list of
the vendor specific Information fields, refer to the SIP Series Reference
Manual.
The BootP/TFTP configuration utility displays this information in the
'Client Info' column (refer to the SIP Series Reference Manual).
Note: This option is not available on DHCP servers.
Serial Parameters
DisableRS232
 [0] = RS-232 serial port is enabled (default).
 [1] = RS-232 serial port is disabled.
The RS-232 serial port can be used to change the networking
parameters (refer to 'Assigning an IP Address Using the CLI' on page
51) and view error / notification messages.
For information on establishing a serial communications link with the
gateway, refer to 'Accessing the CLI' on page 52.
SerialBaudRate
Determines the value of the RS-232 baud rate.
The valid range is any value. It is recommended to use the following
standard values: 1200, 2400, 9600 (default), 14400, 19200, 38400,
57600, 115200.
SerialData
Determines the value of the RS-232 data bit.
 [7] = 7-bit.
 [8] = 8-bit (default).
SerialParity
Determines the value of the RS-232 polarity.
 [0] = None (default).
 [1] = Odd.
 [2] = Even.
SerialStop
Determines the value of the RS-232 stop bit.
 [1] = 1-bit (default).
 [2] = 2-bit.
SerialFlowControl
Determines the value of the RS-232 flow control.
 [0] = None (default).
 [1] = Hardware.
