AudioCodes Mediant 2000 System User Manual

SIP User's Manual 392 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Note: For TDM over IP, the CallerIDTransportType parameter must be set to 0
(transparent).
Below is an example of ini files for two gateways implementing TDM Tunneling for four E1
spans. Note that in this example both gateways are dedicated to TDM tunneling.
Terminating Side:
EnableTDMOverIP = 1
;E1_TRANSPARENT_31
ProtocolType_0 = 5
ProtocolType_1 = 5
ProtocolType_2 = 5
ProtocolType_3 = 5
[PREFIX]
FORMAT PREFIX_Index = PREFIX_DestinationPrefix,
PREFIX_DestAddress, PREFIX_SourcePrefix, PREFIX_ProfileId,
PREFIX_MeteringCode, PREFIX_DestPort;
Prefix 1 = '*,10.8.24.12';
[\PREFIX]
; IP address of the gateway in the opposite
; location
; Channel selection by Phone number.
ChannelSelectMode = 0
;Profiles can be used do define different coders per B-channels
;such as Transparent
; coder for B-channels (time slot 16) that carries PRI ;signaling.
[TrunkGroup]
FORMAT TrunkGroup_Index = TrunkGroup_TrunkGroupNum,
TrunkGroup_FirstTrunkId, TrunkGroup_LastTrunkId,
TrunkGroup_FirstBChannel, TrunkGroup_LastBChannel,
TrunkGroup_FirstPhoneNumber, TrunkGroup_ProfileId,
TrunkGroup_Module;
TrunkGroup 1 = 0,0,0,1,31,1000,1;
TrunkGroup 1 = 0,1,1,1,31,2000,1;
TrunkGroup 1 = 0,2,2,1,31,3000,1;
TrunkGroup 1 = 0,3,3,1,31,4000,1;
TrunkGroup 1 = 0,0,0,16,16,7000,2;
TrunkGroup 1 = 0,1,1,16,16,7001,2;
TrunkGroup 1 = 0,2,2,16,16,7002,2;
TrunkGroup 1 = 0,3,3,16,16,7003,2;
[/TrunkGroup]
[CoderName]
FORMAT CoderName_Index = CoderName_Type, CoderName_PacketInterval,
CoderName_rate, CoderName_PayloadType, CoderName_Sce;
CoderName 0 = 'g7231';
CoderName 1 = 'Transparent';
CoderName 5 = 'g7231';
CoderName 6 = 'Transparent';
[/CoderName]
[TelProfile]
FORMAT TelProfile_Index = TelProfile_ProfileName,
TelProfile_TelPreference, TelProfile_CodersGroupID,
TelProfile_IsFaxUsed, TelProfile_JitterBufMinDelay,
TelProfile_JitterBufOptFactor, TelProfile_IPDiffServ,
TelProfile_SigIPDiffServ, TelProfile_DtmfVolume,
TelProfile_InputGain, TelProfile_VoiceVolume,
TelProfile_EnableReversePolarity,
TelProfile_EnableCurrentDisconnect,
TelProfile_EnableDigitDelivery, TelProfile_EnableEC,
TelProfile_MWIAnalog, TelProfile_MWIDisplay,
