SIP User's Manual 398 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 11-2: Mediant 2000 Selected Technical Specifications
Function Specification
Physical
AC Power Supply
Universal 90 to 260 VAC 1A max, 47-63 Hz
Option for a dual redundant power supply.
AC Power Consumption
1 or 2 span: 39.7 W
4 spans: 42.1 W (approximated)
8 spans: 45.3 W
DC Power Supply
(optional)
36 to 72 VDC (nominal 48 VDC), 4A max, floating input
DC Power Consumption
1 or 2 span: 28.8 W
4 spans: 32.8 W
8 spans: 36.4 W
Environmental (DC)
Operation Temp: 0 to 40 °C (32 to 104 °F)
Short Term Operation Temp (per NEBS): 0 to 55 °C (32 to 131 °F)
Storage: -40 to 70 °C (-40 to 158 °F)
Humidity: 10 to 90% non-condensing
Environmental (AC)
Operation Temp: 0 to 40 °C (32 to 104 °F)
Storage: -40 to 70 °C (-40 to 158 °F)
Humidity: 10 to 90% non-condensing
Hot Swap
cPCI cards are full hot swap supported
Power supplies are redundant but not hot swappable
Enclosure Dimensions
445 x 44 x 300 mm (17.5 x 1.75 x 12 inches)
Weight
Approx. 4.8 kg fully populated (16 spans); 4.2 kg for 1 span
Installation
1U 19-inch 2-slot cPCI chassis; rack-, shelf-, or desktop-mount options.
Rack mount with 2 side brackets; optional -- 2 extra (rear) side brackets.
Type Approvals
Telecommunication
Standards
IC CS03; FCC part 68
Chassis and Host telecom card are approved to the following telecom
standards: IC CS03; FCC part 68; CTR 4, CTR 12 & CTR 13; JATE;
Anatel, Mexico Telecom, Russia CCC, ASIF S016, ASIF S038.
Safety and EMC
Standards
UL 60 950-1, FCC part 15 Class B, (Class A with SUN 2080 CPU card)
CE Mark (EN 55022 Class B (Class A with SUN 2080 CPU card), EN
60950-1, EN 55024, EN 300 386), TS001
Environmental
NEBS Level 3: GR-63-Core, GR-1089-Core, Type 1 & 3. Approved for
DC powered version.
Complies with ETS 301019; ETS 300019-1, -2, -3. (T 1.1, T 2.3, T3.2).
Approved for AudioCodes or DC powered versions.
