SIP User's Manual 400 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 11-3: TP-1610 Selected Technical Specifications
Function Specification
RS-232
Console port - DB-9
Physical
Physical
6U single cPCI slot. PICMG 2.0, R2.1 and R2.16 and R.3.0
CompactPCIâ„¢ card
Supply Voltages and
Power Consumption
(typical)
480 channels: 40.7 W; 3 A at 5 V; 7.8 A at 3.3 V
240 channels: 24 W; 1.5 A at 5 V; 5 A at 3.3 V
120 channels: 18.4 W; 0.9 A at 5 V; 4.2 A at 3.3 V
Environmental
Humidity: 10 to 90% non-condensing
Cooling
500 LFM at 50°C Ambient temp. supporting 480 ports, 400 Linear Feet
per Minute (LFM) at 50°C ambient temp. supporting 400 ports
300 LFM at 50 °C ambient temp. supporting 240 ports
Hot Swap
Full hot swap supported blades
Type Approvals
Telecommunication
Standards
IC CS03, FCC part 68 CTR4, CTR12 , CTR13, JATE, TS.016, TSO,
Anatel, Mexico Telecom
Safety and EMC
Standards
UL 60950, FCC part 15 Class B, CE Mark (EN55022, EN60950,
EN55024, EN300 386)
