SIP User's Manual 78 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-8: General Parameters (Protocol Definition)
Parameter Description
Use “user=phone” in From Header
[IsUserPhoneInFrom]
[0] No = Doesn't use ';user=phone' string in From header
(default).
[1] Yes = ';user=phone' string is part of the From header.
Use Tel URI for Asserted Identity
[UseTelURIForAssertedID]
Determines the format of the URI in the P-Asserted and P-
Preferred headers.
[0] Disable = 'sip:' (default).
[1] Enable = 'tel:'.
Tel to IP No Answer Timeout
[IPAlertTimeout]
Defines the time (in seconds) the gateway waits for a 200 OK
response from the called party (IP side) after sending an
INVITE message. If the timer expires, the call is released.
The valid range is 0 to 3600. The default value is 180.
Enable Remote Party ID
[EnableRPIheader]
Enable Remote-Party-ID (RPI) headers for calling and called
numbers for TelÆIP calls.
Valid options include:
[0] Disable (default).
[1] Enable = RPI headers are generated in SIP INVITE
messages for both called and calling numbers.
dd Number Plan and Type to Remote
Party ID Header
[AddTON2RPI]
[0] No = TON/PLAN parameters aren't included in the
RPID header.
[1] Yes = TON/PLAN parameters are included in the RPID
header (default).
If RPID header is enabled (EnableRPIHeader = 1) and
AddTON2RPI = 1, it's possible to configure the calling and
called number type and number plan using the Number
Manipulation tables for TelIP calls.
