SIP User's Manual 80 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-8: General Parameters (Protocol Definition)
Parameter Description
Use Source Number as Display Name
[UseSourceNumberAsDisplayName]
Applicable to Tel-to-IP calls.
 [0] No = The Tel Source Number is used as the IP Source
Number and the Tel Display Name is used as the IP
Display Name (if Tel Display Name is received). If no
Display Name is received from the Tel side, the IP Display
Name remains empty (default).
 [1] Yes = If a Tel Display Name is received, the Tel
Source Number is used as the IP Source Number and the
Tel Display Name is used as the IP Display Name. If no
Display Name is received from the Tel side, the Tel
Source Number is used as the IP Source Number and
also as the IP Display Name.
 [2] Overwrite = The Tel Source Number is used as the IP
Source Number and also as the IP Display Name (even if
the received Tel Display Name is not empty).
Use Display Name as Source Number
[UseDisplayNameAsSourceNumber]
Applicable to IP-to-Tel calls.
 [0] No = The IP Source Number is used as the Tel Source
Number and the IP Display Name is used as the Tel
Display Name (if IP Display Name is received). If no
Display Name is received from IP, the Tel Display Name
remains empty (default).
 [1] Yes = If an IP Display Name is received, it is used as
the Tel Source Number and also as the Tel Display Name,
the Presentation is set to Allowed (0). If no Display Name
is received from IP, the IP Source Number is used as the
Tel Source Number and the Presentation is set to
Restricted (1).
For example: When the following is received 'from: 100
<sip:200@201.202.203.204>', the outgoing Source Number
and Display Name are set to '100' and the Presentation is set
to Allowed (0).
When the following is received 'from:
<sip:100@101.102.103.104>', the outgoing Source Number
is set to '100' and the Presentation is set to Restricted (1).
