AudioCodes Mediant 2000 System User Manual

SIP User's Manual 88 Document #: LTRT-68806
Mediant 2000 & TP-1610 & TP-260/UNI
Table 5-9: Proxy & Registration Parameters
Parameter Description
First Redundant Proxy
IP Address
[ProxyIP]
IP addresses of the first redundant Proxy you are using.
Enter the IP address as FQDN or in dotted decimal notation (e.g.,
192.10.1.255). You can also specify the selected port in the format <IP
Address>:<port>.
Notes:
 This parameter is available only if you select 'Use Proxy' in the 'Enable
Proxy' field.
 When port number is specified, DNS NAPTR/SRV queries aren't
performed, even if ProxyDNSQueryType is set to 1 or 2.
 For the ini file, the IP address of the first redundant Proxy are defined by
the second repetition of the ini file parameter ProxyIP.
Second Redundant
Proxy IP Address
[ProxyIP]
IP addresses of the second redundant Proxy you are using.
Enter the IP address as FQDN or in dotted decimal notation (e.g.,
192.10.1.255). You can also specify the selected port in the format <IP
Address>:<port>.
Notes:
 This parameter is available only if you select 'Use Proxy' in the 'Enable
Proxy' field.
 When port number is specified, DNS NAPTR/SRV queries aren't
performed, even if ProxyDNSQueryType is set to 1 or 2.
 For the ini file, the IP address of the second redundant Proxy is defined
by the third repetition of the ini file parameter ProxyIP.
Third Redundant Proxy
IP Address
[ProxyIP]
IP addresses of the third redundant Proxy you are using.
Enter the IP address as FQDN or in dotted decimal notation (e.g.,
192.10.1.255). You can also specify the selected port in the format <IP
Address>:<port>.
Notes:
 This parameter is available only if you select 'Use Proxy' in the 'Enable
Proxy' field.
 When port number is specified, DNS NAPTR/SRV queries aren't
performed, even if ProxyDNSQueryType is set to 1 or 2.
 For the ini file, the IP addresses of the third redundant Proxy is defined
by the fourth repetition of the ini file parameter ProxyIP.
Redundancy Mode
[ProxyRedundancyMo
de]
 [0] Parking = gateway continues working with the last active Proxy until
the next failure (default).
 [1] Homing = gateway always tries to work with the primary Proxy server
(switches back to the main Proxy whenever it's available).
Note: To use ProxyRedundancyMode, enable Keep-alive with Proxy option
(EnableProxyKeepAlive = 1 or 2).
