- INSTALLER 7 & 11kW HRC
70
HIGH TEMPERATURE HEAT PUMP -
32
To access the control data, such as pressure readings (in bar)
and all the temperatures read by the sensors (in °C), press and
hold down the dial for 3 seconds. While the dial is pressed down,
"display"will appear on the screen.
• Turn the dial to the right to scroll through the display options
(the values given below are examples) :
5.2 - Displaying the control values
Pt / o p t
0
A M B I e nc e
0
o u t s i de
- 3 5°C
h e a t cu r v e
1 6 . 0 °C
h p i n pu t
0 . 0°C
h p o u tp u t
0 . 0°C
A I R h p
0 . 0°C
E V A P O
0 . 0°C
C O M P R ES --1
0 . 0°C
C O M P R ES --2
0 . 0°C
P i l o t
- 5 0°C
P R E S S u r e
- 2 .0
sh e d d in g
0
N.B: Temperature
display
If 2 heating zones are set, the
temperature is displayed for each
zone
N.B: =If the heating zones
are controlled by a thermostat
rather than a room temperature
sensor, the display will show:
(heating request = 1 ;
comfort mode= 0)
A M B I e NC E 1
1 9 . 0 °C
example
A M B I e NC E 1
1
example
• Press on the dial or the
key to return to the main screen.
• Press on the dial or the key to return to the main screen.
5.3 - User Menu
N.B: The screen only
displays information for the DHW
sensor if it has been set up. See §
"Installer menu / Con guration"
N.B: If the DHW zone is
controlled by an aquastat (heating
request = 1;
comfort mode = 0)
N.B: If the swimming
pool kit is connected and
activated, both the temperature
and the  ow rate (no  ow rate
detected = 0;  ow rate detected =
1) will be automatically displayed.
dh w s en s o .
5 3 °C
example
A Q U A S TA T
0
example
sw i m . p o o l
2 3 . 5 °C
example
p o o l fl o w
1
example
The User Menu allows you to access the settings for heating
modes, operating and stopping the appliance, and also to view
the temperatures in the installation.
• Press
to access the User Menu.
Enter
Enter
Enter
h o l i d ay s
ov e r ri d e
se t t i n g
Switch to holiday mode
Override heating mode in
progress
Setting target temperatures
