auer HRC70 - Appendices; A1 - Dimensions; A1.1 - HRC 70 Heat Pump

- INSTALLER 7 & 11kW HRC
70
HIGH TEMPERATURE HEAT PUMP -
52
APPENDICES
A1 - Dimensions
A1.1 - HRC
70
Heat Pump
Air sensor
Series n°
Condensates drainage, at the back of the
appliance or through the base
Cable gland for
external heater cable
Electrical power supply
2-core sheathed cable
for linking Heat Pump
to Pilot (10m included,
20m availble to order)
