Automationdirect.com DirectLOGIC DL205 Series User Manual

Power Consumed Power Consumed
Device 5V (mA)
24V Auxilliary
(mA)
Device 5V (mA)
24V Auxilliary
(mA)
CPUs Combination Modules
D2–230 120 0 D2–08CDR 200 0
D2–240 120 0
Specialty Modules
D2–250–1 330 0 H2–PBC 530 0
D2–260 330 0 H2–ECOM 450 0
DC Input Modules
H2–ECOM100 300 0
D2–08ND3 50 0 H2–ECOM-F 640 0
D2–16ND3–2 100 0 H2–ERM(100) 320 0
D2–32ND3(–2) 25 0 H2–ERM–F 450 0
AC Input Modules
H2–EBC 320 0
D2–08NA–1 50 0 H2–EBC–F 450 0
D2–08NA–2 100 0 H2–CTRIO(2) 400 0
D2–16NA 100 0 D2–DCM 300 0
DC Output Modules
D2–RMSM 200 0
D2–04TD1 60 20 D2–RSSS 150 0
D2–08TD1(–2) 100 0 D2–CTRINT 50* 0
D2–16TD1–2 200 80 D2–08SIM 50 0
D2–16TD2–2 200 0 D2–CM 100 0
D2–32TD1(–2) 350 0 D2–EM 130 0
AC Output Modules
F2–CP128 235 0
D2–08TA 250 0 F2–DEVNETS–1 160 0
F2–08TA 250 0 F2–SDS–1 160 0
D2–12TA 350 0
Relay Output Modules
D2–04TRS 250 0
D2–08TR 250 0
F2–08TRS 670 0
F2–08TR 670 0
D2–12TR 450 0
Analog Modules
F2–04AD–1 50 80 F2–02DAS–1 100 50mA per channel
F2–04AD–1L 100 5mA @ 10-30V F2–02DAS–2 100 60mA per channel
F2–04AD–2 110 5mA @ 10-30V F2–4AD2DA 90 80mA**
F2–04AD–2L 60 90mA @ 12V** F2–8AD4DA-1 35 100
F2–08AD–1 100 5mA @ 10-30V F2–8AD4DA-2 35 80
F2–08AD–2 100 5mA @ 10-30V F2–04RTD 90 0
F2–02DA–1 40 60** F2–04THM 110 60
F2–02DA–1L 40 70mA @ 12V**
F2–02DA–2 40 60
F2–02DA–2L 40 70mA @ 12V**
F2–08DA–1 30 50mA**
F2–08DA–2 60 140
*requires external 5VDC for outputs
**add an additional 20mA per loop
DL205 User Manual, 4th Edition, Rev. B
