Automationdirect.com DirectLOGIC DL205 Series User Manual

DL205 User Manual, 4th Edition, Rev. B
2–46
Chapter 2: Installation, Wiring and Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
D2–08TR, Relay Output
0
2
4
6
8
Points
0.5A / Pt.
COM
OUTP UT
To L E D
Inte r nal module circuitry
6.3A
5--240 VAC
L
5-- 30 VDC
1A/Pt.
C
C
0
1
2
3
4
5
6
7
Internally
conne cted
L
L
L
L
L
L
L
L
5--240 VAC
5-- 30 VDC
0 10 20 30 40 50 55
Ambient Temperature (˚C/˚F )
32 50 68 86 104 122 131
C˚
F˚
C
C
0
4
1
5
2
6
3
7
5-240VAC
1A 50/60Hz
D2--08TR
OUT RELA Y
D2--08TR
0
1
2
3
4
5
6
7
L
L
5--30VD C
5mA- -1A
Derating Chart
D2-08TR Relay Output
Outputs per Module
8
Outputs Points Consumed
8
Commons per Module
1 (2 I/O terminals)
Output Type
Relay, form A (SPST)
Operating Voltage
5-30 VDC; 5-240 VAC
Peak Voltage
30 VDC, 264 VAC
ON Voltage Drop
N/A
AC Frequency
47 to 60 Hz
Minimum Load Current
5mA @ 5VDC
Max Load Current (resistive)
1A/point; 4A/common
Max Leakage Current
0
.1 mA @265 VAC
Max Inrush Current
O
utput: 3A for 10 ms
C
ommon: 10A for 10 ms
Base Power Required 5VDC
250 mA
OFF to ON Response
12 ms
ON to OFF Response
10 ms
Terminal Type (included)
Removable; D2-8IOCON
Status Indicator
Logic side
Weight
3.9 oz. (110g)
Fuses
One 6.3A slow blow, replaceable
Order D2-FUSE-3 (5 per pack)
Typical Relay Life (Operations)
Voltage/Load Current Closures
24 VDC Resistive 1A 500k
24 VDC Solenoid 1A 100k
110 VDC Resistive 1A 500k
110 VDC Solenoid 1A 200k
220 VAC Resistive 1A 350k
220 VAC Solenoid 1A 100k
