Chapter 5: Standard RLL Instructions - Immediate
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
Or Immediate (ORI)
The Or Immediate connects two contacts in parallel. The
status of the contact will be the same as the status of the
associated input point at the time the instruction is executed.
The image register is not updated.
Or Not Immediate (ORNI)
The Or Not Immediate connects two contacts in parallel.
The status of the contact will be opposite the status of the
associated input point at the time the instruction is executed.
The image register is not updated.
In the following example, when X1 or X2 is on, Y5 will energize.
In the following example, when X1 is on or X2 is off, Y5 will energize.
1
B
ENT
ENT
2
C
ENT
5
F
X1
X2
Y5
OUT
Handheld Programmer KeystrokesDirectSOFT
STR
$
OR
Q
SHFT
8
I
OUT
GX
ENT
5
F
ENT
2
C
1
B
ENT
X1
X2
Y5
OUT
Handheld Programmer Keystrokes
DirectSOFT
STR
$
SHFT
8
I
ORN
R
OUT
GX
Operand Data Type DL230 Range DL240 Range DL250-1 Range DL260 Range
aaa aaa aaa aaa
Inputs X 0–177 0–477 0–777 0–1777
DS Implied
HPP Used
