Automationdirect.com DirectLOGIC DL205 Series User Manual

DL205 User Manual, 4th Edition, Rev. B
5–150
Chapter 5: Standard RLL Instructions - Table
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
Fill (FILL)
The Fill instruction fills a table of up to 255 V-memory
locations with a value (Aaaa), which is either a V-memory
location or a 4-digit constant. The function parameters are
loaded into the first level of the accumulator stack and the
accumulator by two additional instructions. Listed below are the steps necessary to program
the Fill function.
Step 1: Load the number of V-memory locations to be filled into the first level of the accumulator
stack. This parameter must be a HEX value, 0 to FFFF.
Step 2: Load the starting V-memory location for the table into the accumulator. This parameter must
be a HEX value.
Step 3: Insert the Fill instructions which specifies the value to fill the table with.
Helpful hint: — For parameters that require HEX values when referencing memory locations,
the LDA instruction can be used to convert an octal address to the HEX equivalent and load
the value into the accumulator.
In the following example, when X1 is on, the constant value (K4) is loaded into the
accumulator using the Load instruction. This value specifies the length of the table and is
placed on the first level of the accumulator stack when the Load Address instruction is
executed. The octal address 1600 (V1600) is the starting location for the table and is loaded
into the accumulator using the Load Address instruction. The value to fill the table with
(V1400) is specified in the Fill instruction.
FILL
Aaaa
ý
ý
ý
þ
230
240
250-1
260
Standard RLL
Instructions
Handheld Programmer Keystrokes
DirectSOFT
LD
K4
X1
Load the constant value 4
(HEX) into the lower 16 bits
of the accumulator
LDA
O 1600
Convert the octal address
1600 to HEX 380 and load the
value into the accumulator
FILL
V1400
Fill the table with the value
in V1400
V1576
V1577
V1600
V1601
V1602
V1603
V1604
V1605
V1400
STR
$
SHFT
ANDST
L
3
D
SHFT
5
F
8
I
ANDST
L
PREV
ANDST
L
1
B
ENT
4
E
0
A
0
A
ENT
SHFT
ANDST
L
3
D
1
B
6
G
0
A
ENT
0
A
1
B
4
E
0
A
ENT
2 5 0 0
2 5 0 0
2 5 0 0
2 5 0 0
2 5 0 0
Operand Data Type DL260 Range
A aaa
V-memory V All (See page 3 - 56)
Pointer P All V mem (See page 3 - 56)
Constant K 0-FFFF
Discrete Bit Flag Description
SP53 On if V-memory address is out of range
DS Used
HPP Used
