1. Quick Start
This section is a quick guide on how to do most things on the Tiger
Touch. Each section has a link to take you to the appropriate manual
section for more details.
Softkeys are shown in square brackets like [This].
1.1 Patching fixtures
Press Patch, [Dimmers] or [Fixtures].
For Fixtures, from the softkeys choose fixture manufacturer (type on
keyboard to filter the list) then fixture type, then fixture mode.
Set [DMX Line] and [Address]. Console will automatically set these if
you don’t change them.
Press buttons in the Fixtures window to patch the fixture. (Section
3.1.3, p48).
To patch a number of dimmers or fixtures at once, drag over buttons
to draw a selection box on the screen. Or, set [Quantity] in the patch
menu.
To change DMX address or line, use [Repatch Fixtures]. (Section
3.2,
p
53).
View fixture patch
To see an overview screen of how the console is patched, press
View
then Patch (Section
3.2.1 , p53).
Setting fixture options
Press Patch, [Edit Fixtures], or use the Patch View screen.
1.2 Controlling fixtures
Select fixtures for control by pressing select buttons.
Press Locate to “home” selected fixtures with lamp on. . (Section
4.1.2. p66). Hold locate and press attribute button to remove that
attribute from the locate (e.g. to locate without changing pan/tilt,
hold Locate and press Pan/Tilt).
Select attribute to control using attribute bank buttons (below the
wheels, or right hand edge of console for Tiger Touch mk1) , then
turn the wheels to set fixture. Display shows which attribute each
wheel is controlling. (Section
4.1.5, p69).
Open Attribute window onscreen (
View, Attribute Options) to select
attributes from buttons. (Section
4.1.6, p71).
Use Palettes to store often-used colours, positions etc. for instant
recall, see next page.
Shapes (effects)
Select fixtures. The order of fixture selection is used by shapes.
